10 Pin IDC Locking Right Angle Header
A right-angle 10-pin IDC box header for PCB mounting, with a locking mechanism to secure ribbon cable connections. The 2.54mm (0.1") pitch double-row header features gold-plated pins and solder-tag attachment.
Specifications
- Type – Double-row box header (plug)
- Pins – 10 (2×5)
- Pin Spacing – 2.54mm (0.1")
- Orientation – Right angle (horizontal mount)
- Locking – Header locking mechanism for secure cable retention
- Attachment – Solder tag for PCB mounting
- Pin Material – Gold plated
Dimensions
- A – 32mm
- B – 10mm
- C – 22mm
- D – 18mm
Ideal For
- IDC ribbon cable connections on custom PCBs
- ISP/JTAG/SWD programming headers
- Board-to-cable interconnects requiring secure locking
