The Waveshare GC2093 2MP USB Camera Module delivers 1920×1080 resolution with wide dynamic range (WDR) for clear imaging even in challenging lighting conditions. Featuring a fixed-focus lens with a 170° diagonal field of view and an onboard microphone, it provides a complete audiovisual capture solution.

The module connects via USB 2.0 with plug-and-play operation — no drivers required. Its compact 38×38 mm form factor fits easily into enclosures and custom builds, supporting both MJPG and YUY2 image formats.

Key Features

• 2MP Resolution – 1920×1080 static and video capture with GC2093 sensor
• Wide Dynamic Range – 81 dB linear, 105 dB HDR for balanced exposure in mixed lighting
• 170° Field of View – 170.2° diagonal, 144° horizontal, 77.6° vertical coverage
• Fixed Focus – No manual adjustment needed, consistent image quality
• Onboard Microphone – Built-in audio capture for multimedia applications
• Plug and Play – USB 2.0 connection, no drivers required
• M12 Lens Mount – Standard mount for optional lens changes

Specifications

• Sensor – GC2093 (1/2.9 inch)
• Resolution – 2 MP (1920×1080)
• Interface – USB 2.0
• Aperture – F2.2
• Effective Focal Length – 2.28 mm
• Field of View – 170.2° (D) / 144° (H) / 77.6° (V)
• Focus – Fixed
• Dynamic Range – 81 dB linear / 105 dB HDR
• IR Filter – 650 nm
• Image Formats – MJPG, YUY2
• Power – 5 V ± 5%, 180 mA
• Dimensions – 38.00 × 38.00 × 19.01 mm
• Weight – 38 g

Ideal For

• Wide-angle surveillance and monitoring
• Video streaming and conferencing
• Embedded vision projects
• Multimedia capture with integrated audio

Package Contents

• 1× GC2093 2MP USB Camera Module (A)
• 1× USB-A to 5-pin cable

Resources

• Waveshare Wiki – GC2093 2MP USB Camera (A)
