A 3-pin straight locking header with 3.96 mm (0.156") pitch and crimp pins. Commonly used as a power connector on PCBs and switchmode power supplies. The locking mechanism ensures a secure connection, and connectors can be stacked end-to-end for larger configurations.

Key Features

• 3.96 mm Pitch – Standard 0.156" spacing for power connections
• Crimp Attachment – Crimp pins included for wire termination
• Locking & Polarised – Secure connection with keyed housing
• End-to-End Stackable – Combine for larger pin counts
• Rated 250 V @ 7 A AC/DC – Suitable for power distribution

Specifications

• Number of Pins: 3
• Pin Spacing: 3.96 mm (0.156")
• Type: Single Row Header Plug
• DC/AC Voltage: 250 V
• Insulation Resistance: 500 MΩ
• Dielectric Voltage: 1500 V
• Wire Pull-Out Force: 2.85 kg
• Unmating Force: 150 g
• Durability: 25 cycles
• Housing: Nylon, UL 94V-2
• Operating Temperature: −40 to +105°C
• Mounting: PCB

Ideal For

• PCB power connections
• Switchmode power supply output connectors
• Custom wiring harnesses requiring locking connectors

Package Contents

• 1× 3-Pin Locking Header with Crimp Pins (3.96 mm pitch)
