The Adafruit Micro-Lipo Charger is a tiny, easy-to-use charger for single-cell 3.7V/4.2V lithium polymer and lithium ion rechargeable batteries. Simply plug a USB-C cable into any USB power source and connect your battery via the JST connector — two LEDs show charging status at a glance (red = charging, green = complete).

Charging uses a three-stage process: preconditioning, constant-current fast charge, then constant-voltage trickle charge to keep the battery topped up. The default 100 mA charge rate works safely with any battery size and USB port. For larger batteries (500 mAh+), solder the on-board jumper to increase the charge current to 500 mA.

Key Features

• USB-C Input – 5V charging from any USB-C cable and power source
• Three-Stage Charging – Preconditioning, constant-current, and trickle charge
• 100 mA Default Charge Rate – Safe for all battery sizes; adjustable to 500 mA via solder jumper
• Dual Status LEDs – Red (charging) and green (complete)
• JST Battery Connector – Standard 2-pin JST PH for LiPo/LiIon batteries
• Breakout Pads – 0.1" pads for 5V, D−, D+, GND, and VBAT
• Compact Size – Small enough for desk use or permanent project mounting

Ideal For

• Charging LiPo/LiIon batteries for portable projects
• Wearable electronics with rechargeable batteries
• Desk-side battery charging station
• Embedding in projects for built-in charging capability

Package Contents

• 1× Adafruit Micro-Lipo Charger (assembled, ready to use)
