The MCP3002 is a 10-bit analog-to-digital converter (ADC) with a simple SPI interface, available in a breadboard-friendly 8-pin DIP package. Use it to add analog input capability to microcontrollers that lack an ADC, or to expand the number of available analog channels on your project.

Key Features

• 10-Bit Resolution – 1024 discrete levels for precise analog measurement
• SPI Interface – Simple 3-wire communication with any microcontroller
• 2 Input Channels – Read two analog signals independently
• Wide Supply Range – 2.7V to 5.5V operation
• High Sample Rate – Up to 75,000 samples per second
• Low Power Shutdown – Power-saving mode when not in use
• DIP Package – 8-pin DIP, breadboard and perfboard friendly

Specifications

• IC – Microchip MCP3002
• Resolution – 10-bit
• Channels – 2
• Interface – SPI (3-wire)
• Supply Voltage – 2.7V to 5.5V
• Sample Rate – Up to 75 ksps
• Package – 8-pin DIP

Ideal For

• Adding ADC capability to digital-only microcontrollers
• Expanding analog inputs on Arduino or Raspberry Pi
• Sensor data acquisition projects
• Breadboard prototyping

Package Contents

• 1× MCP3002 10-Bit ADC (8-pin DIP)
