The Black Magic Probe V2.1 is a next-generation JTAG/SWD debugging tool for ARM Cortex microprocessors. Unlike traditional debug dongles, it doesn't require OpenOCD or STLink — the probe itself is a GDB server, emulated through USB serial. Simply connect via GDB and start debugging directly.

It also includes a bonus TTL-level USB-serial adapter with socket headers for dual GDB + printf debugging. The Black Magic Probe is fully open-source hardware, and your purchase supports ongoing development.

Key Features

• Built-In GDB Server – No OpenOCD or special PC software required
• SWD & JTAG Support – Both debug interfaces on one probe
• 1.7V to 5V Target Support – Wide voltage range for diverse targets
• 3.3V Target Power – Can supply up to 100mA to the target
• TTL Serial Interface – Built-in USB-serial adapter for printf debugging
• Semihosting Support – Redirect target I/O to the host
• Cross-Platform – Works on Linux, Mac, and Windows
• IDE Compatible – Eclipse and other IDEs supported

Debugging Capabilities

• Load applications into target Flash or RAM
• Single-step through code
• Run, halt, and examine CPU registers and memory
• Call stack backtrace
• Up to 6 hardware breakpoints and 4 hardware watchpoints
• Unlimited software breakpoints when running from RAM

Supported Targets (partial list)

• STM32 – F0, F1, F2, F3, F4, F7
• Atmel – SAMD20/21, SAM3N/S/X/U, SAM4L, SAM4S
• Nordic – nRF51, nRF52
• NXP – LPC8xx, LPC11xx, LPC15xx, LPC43xx
• TI – LM3S, TM4C
• Freescale – KL25, KL27, KL02
• SiLabs – EFM32, EZR32
• Broadcom – BCM2836 (Raspberry Pi 2)

Package Contents

• 1× Black Magic Probe V2.1
• 1× SWD/JTAG ribbon cable (0.05" pitch)
• 1× Serial cable (0.1" pin header)

Resources

• Black Magic Probe Documentation
• Supported Targets List
• GitHub – Source Code & Design Files
