The Bus Pirate 5 SOIC/SOP8 SPI Flash Adapter makes it easy to program bare SPI flash memory chips without clips or soldering. The spring-loaded ZIF socket accepts SOP8 packages in both 150 mil and 208 mil widths — the most common flash memory form factors — allowing quick chip insertion and removal.

Simply press down on the socket to retract the spring fingers, place the chip with pin 1 aligned to the marker, and release. The spring fingers grip the chip securely for reliable contact during programming.

Key Features

• Spring-Loaded ZIF Socket – No clips or soldering required
• SOP8 Compatible – Supports 150 mil and 208 mil packages
• Easy Chip Insertion – Press-to-open mechanism with secure spring grip
• Bus Pirate 5 Accessory – Designed for use with the Bus Pirate 5

How to Use

• Insert – Press the socket top to retract the spring fingers, place the chip (pin 1 aligned to the marker), and release
• Remove – Press the socket top again, then lift the chip out with tweezers or turn the socket upside down

Ideal For

• Programming and reading SPI flash memory chips
• Firmware extraction and recovery
• Hardware security research and reverse engineering
• Mobile phone and electronics repair

Package Contents

• 1× SOP8 SPI flash adapter for Bus Pirate 5

Resources

• SPI Flash Adapters Documentation
• Flash Command Reference
• Interfacing Common SPI Flash Chips
• Schematic and PCB (GitHub)
