A DC 12 V four-way solenoid valve with one inlet and four independently controlled outlets. Each outlet has its own control wire, so you can open any combination of the four channels — use one at a time or all four simultaneously. Designed for automated plant watering, aquarium systems, and other fluid control projects.

Compact enough for DIY builds, with mounting holes on both sides for secure installation. Compatible with both water and air applications.

Specifications

• Working Voltage – DC 12 V (rated range: 6–12 V DC)
• Working Current – <280 mA at 6 V / <160 mA at 12 V
• Power – <3 W
• Pressure Range – 0–450 mmHg
• Fluid Compatibility – Water or air
• Inlet/Outlet Diameter – 8 mm
• Channels – 1 inlet, 4 independently controlled outlets
• Dimensions – ~80 mm (L) × ~48 mm (H)
• Operating Temperature – 0°C to 55°C
• Service Life – 50,000+ cycles (10 s inflate / 5 s exhaust in 500 cc container)

Key Features

• Independent Channel Control – Each of the four outlets has a separate control wire
• Compact Design – Small footprint suitable for enclosed DIY projects
• Mounting Holes – Fixed holes on both sides for secure installation
• Versatile – Works with water or air

Ideal For

• Automated plant watering systems
• Smart garden and greenhouse irrigation
• Aquarium water control
• Pneumatic DIY projects

Package Contents

• 1× DC 12 V Four-Way Solenoid Valve
