This dual-edge side-light NeoPixel strip features LEDs on both the top and bottom of the flexible PCB, producing an even glow from both sides. With 60 LED pairs per metre (120 LEDs total), both LEDs in each segment display the same colour simultaneously, making it ideal for edge-lighting where the strip is visible from multiple angles.

The strip is built on a flexible white PCB with weather-resistant sheathing and can be cut at the marked halfway point. JST SM 3-pin connectors on both ends allow easy daisy-chaining or direct wiring. It uses the standard WS281x (NeoPixel) protocol on a single data line.

Key Features

• Dual-Sided LEDs – LEDs on both top and bottom edges for light in both directions
• 120 LEDs per Metre – 60 paired segments, each with two LEDs showing the same colour
• Individually Addressable – Standard NeoPixel (WS281x) protocol, 60 addressable segments per metre
• Flexible White PCB – Curves around shapes and corners, with weather-resistant sheathing
• Cuttable – Cut at the marked line with wire cutters; solder to 0.1″ copper pads to extend
• JST SM Connectors – 3-pin connectors on both ends for easy hookup

Specifications

• LED Count – 120 LEDs (60 addressable segments) per metre
• Strip Length – 1 metre
• Supply Voltage – 5 V DC
• Protocol – WS281x (NeoPixel)
• PCB Colour – White
• Connectors – JST SM 3-pin (both ends)

Ideal For

• Edge and accent lighting on thin surfaces
• Backlighting panels and signs
• Costumes and wearable projects
• Curved and contoured lighting installations

Resources

• NeoPixel Uberguide – Library, example code, and wiring for Arduino, CircuitPython, and Raspberry Pi

Package Contents

• 1× Dual Edge Side-Light NeoPixel LED Strip (1 m, 120 LEDs)
