The ELE CAN-Bus Shield V1.5 adds CAN-Bus communication capability to your Arduino. Built around the Microchip MCP2515 CAN controller and MCP2551 CAN transceiver, it supports CAN V2.0B at speeds up to 1 Mb/s with both standard (11-bit) and extended (29-bit) frames.

The shield connects via a standard 9-pin sub-D connector, making it ideal for OBD-II automotive diagnostics. An onboard microSD card holder allows direct data logging without additional hardware.

Key Features

• MCP2515 + MCP2551 – CAN controller and transceiver for reliable bus communication
• CAN V2.0B – Up to 1 Mb/s with standard (11-bit) and extended (29-bit) data and remote frames
• SPI Interface – Up to 10 MHz for fast communication with the host Arduino
• Two Receive Buffers – Prioritised message storage
• 9-Pin Sub-D Connector – Industry-standard connection for OBD-II cables
• MicroSD Card Holder – Onboard storage for data logging
• Two LED Indicators – Visual status feedback

Compatibility

• Arduino Mega
• Arduino Leonardo

Ideal For

• Automotive OBD-II diagnostics and data logging
• Industrial CAN-Bus communication
• Vehicle sensor monitoring
• Machine tool interfacing

Resources

• Wiki and usage guide
• Design files (ZIP)
