The ESP32-C6-DevKitM-1 is an entry-level development board built around the ESP32-C6-MINI-1 module, featuring a RISC-V 32-bit single-core processor running at up to 160 MHz. It integrates Wi-Fi 6 (2.4 GHz), Bluetooth 5 (LE), Zigbee 3.0, and Thread 1.3 — making it one of the most connectivity-rich ESP32 boards available.

Most I/O pins are broken out to headers on both sides of the board for easy breadboard mounting or jumper wire connections. The board includes two USB Type-C ports: one via a USB-to-UART bridge for programming and serial communication, and another connected directly to the ESP32-C6 chip supporting USB 2.0 full-speed and JTAG debugging.

Key Features

• ESP32-C6 RISC-V Processor – 32-bit single-core CPU running at up to 160 MHz
• Wi-Fi 6 (802.11ax) – 2.4 GHz band support for modern wireless connectivity
• Bluetooth 5 (LE) – Low-energy Bluetooth for IoT device communication
• Zigbee 3.0 & Thread 1.3 – IEEE 802.15.4 support for mesh networking and smart home protocols
• 4 MB SPI Flash – Built into the ESP32-C6FH4 chip package
• Dual USB Type-C Ports – One for UART programming, one for native USB 2.0 and JTAG
• Low-Power Co-Processor – Monitor peripherals while the main CPU is powered off
• Addressable RGB LED – Driven by GPIO8 for status indication
• Boot & Reset Buttons – For firmware download mode and system reset

Specifications

• Processor – ESP32-C6, RISC-V 32-bit single-core (up to 160 MHz)
• ROM – 320 KB
• SRAM – 512 KB HP + 16 KB LP
• Flash – 4 MB SPI
• Crystal Oscillator – Integrated 40 MHz
• Operating Voltage – 3.0–3.6 V
• Operating Temperature – –40 °C to 85 °C
• Module – ESP32-C6-MINI-1 (on-board PCB antenna)

Ideal For

• Smart home devices with Zigbee/Thread/Matter support
• Low-energy IoT sensor hubs and data loggers
• Industrial automation and health care devices
• Prototyping multi-protocol wireless applications

Package Contents

• 1× ESP32-C6-DevKitM-1 Development Board

Resources

• User Guide
• ESP32-C6 Datasheet (PDF)
• ESP32-C6-MINI-1 Datasheet (PDF)
