An 8×8 matrix of 64 individually addressable DotStar (APA102) RGB LEDs on a flexible PCB. Each pixel delivers 24-bit colour and is controlled via a fast 2-wire SPI protocol that's less timing-sensitive than NeoPixel, making it easier to drive from any microcontroller.

DotStar LEDs feature built-in high-frequency PWM for smooth colour blending and act as shift registers — letting you daisy-chain as many LEDs as you need from a single data line. At full white brightness, the matrix can draw up to 4 A, so a suitable 5 V power supply is recommended.

Key Features

• 64 RGB LEDs – 8×8 individually addressable matrix
• DotStar (APA102) – 2-wire SPI protocol, less timing-critical than NeoPixel
• 24-Bit Colour – 8 bits per channel (red, green, blue)
• High-Frequency PWM – Smooth colour transitions and blending
• 5050 SMD Package – Compact 5 × 5 mm LEDs
• Flexible PCB – Can be shaped to curved surfaces
• 5 V Input – Up to 4 A at full white brightness

Ideal For

• LED displays and scrolling text projects
• Wearable electronics and costumes
• Ambient lighting and art installations
• Pixel-art animations

Package Contents

• 1× Flexible DotStar 8×8 LED Matrix (64 RGB pixels)

Resources

• DotStar LED Guide – Wiring, Power & Example Code
