A 128×64 pixel LCD shield with LED backlight that plugs directly into Arduino boards. Supports English, Chinese, and bitmap image display. Includes a built-in 5-direction joystick for menu navigation and interactive control, plus breakout pins for additional I/O.

Key Features

• 128×64 LCD Display – LED backlit with >150° viewing angle
• 5-Direction Joystick – Built-in analog joystick on pin A0 for menu navigation
• Arduino Shield Format – Plugs directly into Arduino Uno and compatible boards
• Extended I/O – 5 spare analogue pins and 8 digital pins broken out
• Backlight Control – Controllable via digital pin D7
• Reset Button – On-board reset for convenience

Specifications

• Display – 128×64 pixels, LED backlight
• Power Supply – 3.3V
• Pins Used – D7, D8, D9, D10, D11, D13, A0
• Dimensions – 60 × 55 × 20 mm

Ideal For

• Arduino menu-driven interfaces
• Prototyping with graphical display output
• Interactive projects with joystick control
• Status dashboards and data visualisation

Package Contents

• 1× LCD12864 Shield

Resources

• DFRobot Wiki
• Schematic (PDF)
• Bitmap Converter Tool
