The LilyPad Accelerometer is a three-axis accelerometer based on the Analog Devices ADXL335, designed for the LilyPad wearable e-textile system. It detects joint movement, inclination, and vibration, outputting 0–3 V analogue signals on the X, Y, and Z axes.

The board features large sewable pads and a thin 0.8 mm PCB for comfortable integration into clothing and wearable projects. For tilt angle calculation, the analogue voltage needs to be converted to a gravity value using trigonometry; for basic motion sensing, the raw analogue output can be used directly.

Key Features

• 3-Axis MEMS Accelerometer – ADXL335 from Analog Devices
• Analogue Output – 0–3 V on X, Y, and Z axes
• LilyPad Form Factor – 20 mm diameter, sewable pads
• Thin PCB – 0.8 mm for comfortable wearable integration
• Washable

Specifications

• Sensor – ADXL335 (3-axis MEMS accelerometer)
• Output – 0–3 V analogue (per axis)
• Diameter – 20 mm
• PCB Thickness – 0.8 mm

Ideal For

• Wearable electronics and e-textiles
• Motion and gesture detection
• Tilt and inclination sensing

Package Contents

• 1× LilyPad Accelerometer (ADXL335)

Resources

• Schematic (PDF)
• ADXL335 Datasheet (PDF)
• GitHub Repository
