NeoPixel Ring - 24 x 5050 RGBW LEDs w/ Integrated Drivers - Cool White - ~6000K

Product image 1
1 / 5

NeoPixel Ring - 24 x 5050 RGBW LEDs w/ Integrated Drivers - Cool White - ~6000K

This 24-LED NeoPixel Ring features RGBW LEDs (red, green, blue, and cool white ~6000K) in a compact circular form factor with a 65.5 mm outer diameter. Each LED contains an integrated WS2812-style driver, so you only need a single data pin from your microcontroller to control all 24 individually addressable LEDs with 32-bit colour (8-bit PWM per channel × 4 channels).

The rings are chainable — connect the data output of one ring to the input of another to build larger displays. Each LED draws ~18 mA constant current for consistent colour regardless of voltage variation, and no external resistors are needed. Power the ring with 5V DC and you're ready to go.

Key Features

  • 24× RGBW LEDs – 5050-size with integrated drivers and cool white (~6000K) channel
  • Individually Addressable – Control each LED's colour and brightness independently
  • 32-Bit Colour – 8-bit PWM per R, G, B, and W channel
  • Single-Pin Control – Only one digital output pin required (800 kHz protocol)
  • Chainable – Connect multiple rings in series from a single data pin
  • Constant Current Drive – ~18 mA per LED for consistent colour output
  • 65.5 mm Outer Diameter – Compact circular ring layout
  • ~400 Hz PWM Rate – Smooth for stationary applications

Ideal For

  • Task and workbench lighting with cool white tones
  • Wearable electronics and costume lighting
  • Status indicators and circular displays
  • Arduino, Raspberry Pi, and microcontroller projects
Note: RGBW NeoPixels require a library with RGBW support. Using a standard RGB NeoPixel library will produce incorrect results. The Adafruit NeoPixel library supports RGBW — check compatibility if using a different library.

Package Contents

  • 1× NeoPixel Ring with 24 RGBW LEDs (cool white ~6000K), assembled and tested

Resources
