ScanaQuad Logic Analyzer Pattern Generators - SQ200
The ScanaQuad SQ200 is a 4-channel logic analyser and digital pattern generator that helps you capture, decode, and debug digital signals on your embedded systems. With 200 MHz sampling, 4 M samples per channel, and 30+ built-in protocol decoders, it handles everything from simple edge triggers to complex multi-step protocol-based triggering.
The SQ200 can capture and generate simultaneously — stimulate your circuit with test patterns while monitoring its response. The free ScanaStudio V3 software runs natively on Windows, macOS, and Linux.
Key Features
- 200 MHz Max Sampling Rate – High-speed capture for fast digital signals
- 4 Input/Output Channels – Capture, generate, or both simultaneously
- 4 M Samples per Channel – Deep memory for long captures
- 30+ Protocol Decoders – I²C, SPI, RS232, CAN, 1-Wire, JTAG, and more (open source)
- Protocol Trigger – Target specific I²C addresses, CAN frame IDs, or custom patterns
- ±35V Input Protection – Robust inputs for real-world circuits
- Adjustable I/O Voltage – Match your circuit's logic levels
- Adjustable Input Resistance – Minimise loading on sensitive signals
- 2 Differential Input Pairs – For differential signal analysis
- Open Drain Outputs – With optional pull-up
SQ200 Specifications
- Channels – 4 (input/output)
- Max Sampling Rate – 200 MHz
- Memory per Channel – 4 M samples
- Input Protection – ±35V
- Differential Pairs – 2
- Pattern Generator – Yes (simultaneous capture + generate)
- Software – ScanaStudio V3 (Windows, macOS, Linux)
Ideal For
- Embedded systems debugging
- Serial protocol analysis (I²C, SPI, UART, CAN, etc.)
- Digital circuit testing with pattern generation
- Education and electronics labs
Package Contents
- 1× ScanaQuad SQ200 Logic Analyser
Resources
Original: $410.93
-70%$410.93
$123.28Product Information
