The Hitec HS-625MG is a standard-size servo with metal gears and dual ball bearings, delivering strong torque at a competitive price. It produces up to 6.67 kg·cm (94.4 oz·in) of torque at 6.0 V with a speed of 0.15 sec/60°, making it well suited for robotics, mechatronics, and RC applications.

Key Features

• Metal Gears – Three metal gears plus one resin gear for durability
• Dual Ball Bearings – Smooth, reliable operation under load
• High Torque – Up to 6.67 kg·cm (94.4 oz·in) at 6.0 V
• Gold-Plated Connector – Standard 3-pin servo cable
• Multiple Horns Included – Five servo horns for different mounting configurations

Specifications

• Voltage – 4.8–6.0 V
• Torque – 5.40 kg·cm / 76.4 oz·in (4.8 V), 6.67 kg·cm / 94.4 oz·in (6.0 V)
• Speed – 0.18 sec/60° (4.8 V), 0.15 sec/60° (6.0 V)
• Rotation – 180°
• Motor – 3-pole ferrite
• Bearings – Dual ball bearing
• Spline – C1 standard
• Dimensions – 40.6 × 19.8 × 36.6 mm
• Wire Length – 300 mm
• Weight – 55.2 g

Ideal For

• Robotics and mechatronics projects
• RC vehicles and aircraft
• Pan-tilt camera mounts

Resources

• Datasheet (PDF)

Package Contents

• 1× Hitec HS-625MG Servo
• 1× Double arm horn
• 1× Single arm horn
• 1× Four-point horn
• 1× Small white circle horn
• 1× Large black circle horn
• 4× Rubber grommets
• 4× 2 × 15 mm Phillips screws
• 4× Brass eyelets
