The SmartLED Shield V4 bridges your Teensy microcontroller to large LED matrix panels, making it easy to connect the 13 signals required to drive HUB75 displays. It also provides a connection for an external 5V power supply and breaks out all remaining Teensy GPIO pins to a convenient header.

In addition to LED matrix panels, the SmartLED Shield V4 can also drive individual APA102 LEDs, boards, and strips. The shield comes fully assembled with a socket for your Teensy, so it can be removed at any time.

Key Features

• HUB75 LED Matrix Support – Drives large RGB LED matrix panels with all 13 required signals
• APA102 LED Support – Also compatible with APA102 individual LEDs, boards, and strips
• External Power Input – 5V supply connection powers both the display and Teensy
• Breakout Header – All free Teensy GPIO pins brought out for additional use
• Saves GPIO Pins – Frees up four GPIO pins compared to direct wiring
• Fully Assembled – Ready to use with a removable Teensy socket

Compatibility

• Teensy 3.1, 3.2, 3.5, and 3.6

Ideal For

• Large LED matrix displays and signage
• APA102 LED strip installations
• Interactive LED art and visualisations
• LED video walls and tiled displays

Resources

• Getting Started with the SmartLED Shield Guide
