SparkFun Artemis Module - Low Power Machine Learning BLE Cortex-M4F

Product image 1
1 / 4

SparkFun Artemis Module - Low Power Machine Learning BLE Cortex-M4F

The SparkFun Artemis Module is a compact 10 × 15 mm wireless module built around the Ambiq Apollo3 Cortex-M4F processor with BLE 5.0. Running at 48 MHz (with 96 MHz turbo mode), it draws as little as 6 µA per MHz — making it exceptionally power-efficient for battery-powered and always-on applications including machine learning inference at the edge.

The module includes all necessary support circuitry for the Apollo3 processor, and its open-source hardware design can be implemented on low-cost 2-layer PCBs with 8 mil trace/space. Program it using the Arduino core or push further with the advanced HAL for full access to the Cortex-M4F architecture.

Key Features

  • Cortex-M4F Processor – 48 MHz default, 96 MHz turbo mode
  • Ultra-Low Power – 6 µA/MHz (<5 mW), ideal for battery-powered projects
  • BLE 5.0 – Built-in Bluetooth Low Energy
  • 1 MB Flash + 384 KB RAM – Ample space for complex applications
  • Arduino Compatible – Program using the Arduino IDE and SparkFun's Arduino core
  • Compact Module – 10 × 15 mm with all support circuitry included
  • Open Source Hardware – Full design files available for custom carrier board development
  • Certified – FCC, IC, and CE certified; available in tape and reel

Specifications

  • Processor: Ambiq Apollo3 (ARM Cortex-M4F)
  • Clock Speed: 48 MHz (96 MHz turbo)
  • Flash: 1 MB
  • RAM: 384 KB
  • Wireless: BLE 5.0
  • Power: 6 µA/MHz
  • Module Size: 10 × 15 mm
  • Certifications: FCC, IC, CE

Ideal For

  • Ultra-low-power IoT devices
  • Edge machine learning and voice recognition
  • BLE-connected wearables and sensors
  • Custom product development and production scaling

Resources

$6.48

Original: $21.60

-70%
SparkFun Artemis Module - Low Power Machine Learning BLE Cortex-M4F—

$21.60

$6.48

Product Information

Shipping & Returns

Description

The SparkFun Artemis Module is a compact 10 × 15 mm wireless module built around the Ambiq Apollo3 Cortex-M4F processor with BLE 5.0. Running at 48 MHz (with 96 MHz turbo mode), it draws as little as 6 µA per MHz — making it exceptionally power-efficient for battery-powered and always-on applications including machine learning inference at the edge.

The module includes all necessary support circuitry for the Apollo3 processor, and its open-source hardware design can be implemented on low-cost 2-layer PCBs with 8 mil trace/space. Program it using the Arduino core or push further with the advanced HAL for full access to the Cortex-M4F architecture.

Key Features

  • Cortex-M4F Processor – 48 MHz default, 96 MHz turbo mode
  • Ultra-Low Power – 6 µA/MHz (<5 mW), ideal for battery-powered projects
  • BLE 5.0 – Built-in Bluetooth Low Energy
  • 1 MB Flash + 384 KB RAM – Ample space for complex applications
  • Arduino Compatible – Program using the Arduino IDE and SparkFun's Arduino core
  • Compact Module – 10 × 15 mm with all support circuitry included
  • Open Source Hardware – Full design files available for custom carrier board development
  • Certified – FCC, IC, and CE certified; available in tape and reel

Specifications

  • Processor: Ambiq Apollo3 (ARM Cortex-M4F)
  • Clock Speed: 48 MHz (96 MHz turbo)
  • Flash: 1 MB
  • RAM: 384 KB
  • Wireless: BLE 5.0
  • Power: 6 µA/MHz
  • Module Size: 10 × 15 mm
  • Certifications: FCC, IC, CE

Ideal For

  • Ultra-low-power IoT devices
  • Edge machine learning and voice recognition
  • BLE-connected wearables and sensors
  • Custom product development and production scaling

Resources
