A 1 kΩ NTC (negative temperature coefficient) thermistor in a 5 mm radial dipped-epoxy package. The resistance decreases as temperature increases, making it suitable for temperature sensing, thermal compensation, and monitoring applications. Rugged ceramic construction with tinned copper leads for reliable through-hole soldering.

Key Features

• NTC Ceramic Element – Resistance decreases with rising temperature
• 1 kΩ at 25 °C – Standard reference resistance (±10%)
• Dipped Epoxy Package – Rugged and moisture-resistant
• Through-Hole Mounting – Radial leads with 5 mm pitch
• Wide Temperature Range – −20 to +125 °C

Specifications

• Type – NTC thermistor
• Resistance at 25 °C – 1 kΩ (±10%)
• Temperature Range – −20 to +125 °C
• Thermal Dissipation – 6 mW/°C
• Maximum Power – 500 mW
• DC Current Rating – 80 mA
• Package – Radial, dipped epoxy
• Diameter – 5 mm
• Lead Pitch – 5 mm
• Mounting – Through-hole (solder legs)

Ideal For

• Temperature sensing and monitoring
• Thermal compensation in transistor circuits
• Over-temperature protection
• Arduino and microcontroller temperature projects
