The TMP100 Temperature Sensor Module provides accurate digital temperature readings over I2C, making it ideal for environmental monitoring, thermal protection, and thermostat control projects. It supports configurable resolution from 9 to 12 bits and works with both 3.3V and 5V systems via an on-board voltage selector switch.

With a configurable I2C address (up to 8 devices on one bus) and a simple pin header interface, it's easy to integrate with Arduino, Raspberry Pi, and other microcontrollers.

Key Features

• TMP100 Digital Sensor – High-accuracy I2C temperature measurement
• Configurable Resolution – 9 to 12 bits for speed vs precision trade-off
• Dual Voltage Support – Switch between 3.3V and 5V operation
• Configurable I2C Address – 8 addresses available for multi-sensor setups
• Low Power – 45 µA operating, 0.1 µA standby
• Wide Input Voltage – 2.7V to 5.5V

Specifications

• Input Voltage – 2.7–5.5V
• Operating Current – 45 µA (0.1 µA standby)
• Resolution – 9–12 bits
• I2C Address Range – 0x48–0x4F
• I2C Clock Speeds – 100 kHz / 400 kHz / 3.4 MHz
• Accuracy – ±2°C (-25°C to 85°C), ±3°C (-55°C to 125°C)
• Interface – I2C digital output
• Dimensions – 32 × 27 mm (1.23 × 1.06 in)

Ideal For

• Power supply temperature monitoring
• Computer peripheral thermal protection
• Thermostat and climate control projects
• Environmental data logging

Package Contents

• 1× TMP100 Temperature Sensor Module
• 1× 4-Pin Straight Header
• 1× Cable

Resources

• TMP100 Datasheet (PDF)
• Schematic (PDF)
• Wiki Documentation
