The 0.100″ (2.54 mm) 2×5-Pin Straight Female Header is a double-row, 10-pin socket strip designed to mate with standard 0.1″ pitch male headers. The 2×5 configuration is one of the most widely used dual-row sizes, matching standard 10-pin ribbon cable connectors and programming headers.

This pin count is commonly found on AVR ISP 10-pin programming headers, JTAG interfaces, and SWD debug connections, making it a staple connector for embedded development.

Key Features

• 0.1″ (2.54 mm) Pitch – Industry-standard spacing compatible with breadboards and perfboard
• Straight Orientation – Mounts perpendicular to the PCB for standard vertical connections
• 2×5-Pin Configuration – Double-row, 10-position socket matching standard ribbon cable connectors
• Through-Hole Mounting – Solders directly to standard PCBs

Ideal For

• AVR ISP 10-pin programming headers
• JTAG and SWD debug interfaces
• 10-pin ribbon cable connections
• Prototyping and custom interconnects

Package Contents

• 1× 0.100″ (2.54 mm) 2×5-Pin Straight Female Header
