10.1 800x1280 mini-HDMI IPS Display

A 10.1" IPS display with 800 × 1280 resolution and mini-HDMI input, powered via micro-USB at just 500 mA. It supports 100-level backlight brightness adjustment (controllable via script) and works with Raspberry Pi, LattePanda, and other devices with HDMI output across Linux, Windows, and macOS.

The display connects directly to your device with no additional drivers required on most platforms. Note that this is a portrait-orientation screen — on Linux/Raspberry Pi, rotation can be set in the config.txt file, and on Windows, rotation is set in the display settings.

Specifications

  • Screen Size – 10.1"
  • Resolution – 800 × 1280 (WXVGA)
  • Panel Type – IPS
  • Colour Depth – 16.7 M colours
  • Brightness – 200 cd/m² (100-level backlight adjustment)
  • Video Input – Mini-HDMI
  • Power – 5 V / 500 mA via micro-USB
  • Supported Systems – Linux, Windows, macOS
  • Overall Dimensions – 245 × 160 × 9 mm
  • Active Area – 135.36 × 216.68 mm

Ideal For

  • Raspberry Pi and LattePanda desktop setups
  • Portable and embedded display applications
  • Kiosks, dashboards, and information displays

Package Contents

  • 1× 10.1" mini-HDMI IPS display
Note: The micro-USB power and mini-HDMI signal must be connected to the same device (shared GND) to avoid display artefacts. When powering from a Raspberry Pi, ensure your power supply has sufficient capacity for both the Pi and the display (~500 mA additional draw).

Resources
