2.8 TFT Display with Resistive Touchscreen

The 2.8" TFT Display with Resistive Touchscreen is a bare LCD module featuring 320×240 resolution with individual RGB pixel control. Driven by the ILI9341 chipset, it supports SPI (3- or 4-wire), 8-bit parallel, and 16-bit parallel interfaces.

The resistive touchscreen is an analogue type that requires either a microcontroller with analogue inputs or a dedicated touch screen controller (such as the STMPE610). A 50-pin, 0.5mm pitch, top-contact FPC connector is required for connection.

Key Features

  • 2.8" TFT LCD – 320×240 resolution with full RGB pixel control
  • Resistive Touchscreen – Analogue touch overlay compatible with standard touch controllers
  • ILI9341 Driver – Well-supported display controller with extensive library support
  • Multiple Interfaces – SPI (3/4-wire), 8-bit parallel, or 16-bit parallel

Specifications

  • Display Size: 2.8" diagonal
  • Resolution: 320×240 pixels
  • Display Driver: ILI9341
  • Touch Type: 4-wire resistive (analogue)
  • Connector: 50-pin, 0.5mm pitch, top-contact FPC

Ideal For

  • Custom embedded display projects
  • Touch-based user interfaces
  • Integration into bespoke enclosures and PCBs

Package Contents

  • 1× 2.8" TFT LCD Module with Resistive Touchscreen
Warning: This is a bare display module only — no PCB or breakout board is included. A matching 50-pin, 0.5mm pitch FPC connector is required for connection and cannot be soldered directly to a PCB.

Resources
