This 7" HDMI display with capacitive touchscreen supports up to 5 touch points and uses DFRobot's USB free-driver technology — simply plug in via USB for instant touch control with no driver installation required. It works like a keyboard or mouse on any compatible system.

The display supports Windows, Linux, and macOS, and is compatible with LattePanda, Raspberry Pi, and other HDMI devices. Arduino-compatible mounting holes on the back allow direct board attachment. Power is supplied via USB and HDMI — no external power supply needed. A rear potentiometer provides hardware backlight adjustment.

Key Features

• 1024×600 Resolution – Clear display via HDMI interface
• 5-Point Capacitive Touch – USB free-driver technology, plug and play
• Cross-Platform – Supports Windows, Linux, and macOS
• USB-Powered – No external power supply required
• Hardware Backlight Control – Potentiometer on the rear for brightness adjustment
• Arduino Mounting Holes – Compatible screw holes for direct board attachment

Specifications

• Operating Voltage: 5V
• Operating Current: 160 mA (with HDMI)
• Max Current: 1200 mA
• Resolution: 1024×600
• Refresh Rate: 43 Hz (60 Hz not recommended — display may not fill screen)
• Video Interface: HDMI
• Dimensions: 183 × 100 mm
• Mounting Hole Size: 3.1 × 6 mm
• Weight: 328 g

Ideal For

• Raspberry Pi and LattePanda touchscreen projects
• PC touch input and kiosk displays
• Embedded HMI and control panels
• Arduino project displays with direct mounting

Package Contents

• 1× 7" HDMI Display with Capacitive Touchscreen
