The 8-Channel LoRa Gateway HAT turns a Raspberry Pi 3 B+ into a multi-channel LoRa gateway, enabling long-range wireless communication without cellular fees or complex network infrastructure. Built around the SX1301 concentrator chipset, it supports all 8 LoRa channels simultaneously for multi-node communication.

LoRa (Long Range) radio is ideal for deploying IoT sensor networks in rural or remote areas where WiFi and cellular coverage is limited. Unlike single-channel gateways, this 8-channel design handles multiple clients on different LoRa channels without code modifications. The included GPS module enables precise timestamping and geolocation for network synchronisation.

Key Features

• 8-Channel LoRa – SX1301 concentrator supports all 8 channels simultaneously
• 915 MHz Frequency – Australian/US ISM band compatible
• GPS/GNSS – Built-in GPS for timestamping and geolocation
• Pre-Loaded SD Card – 16GB MicroSD card included, ready to use
• Pi HAT Form Factor – Plugs directly onto the Raspberry Pi GPIO header

Also Available

• 8-Channel LoRa Gateway Kit – Complete kit including Raspberry Pi 3 B+, enclosure, and power supply

Ideal For

• IoT sensor networks in remote or rural areas
• LoRa-based environmental monitoring
• Long-range wireless data collection
• Building a LoRaWAN gateway

Package Contents

• 1× 915 MHz LoRa concentrator + GPS shield (SX1301)
• 1× 16GB MicroSD card (pre-loaded)
• 1× Magnetic mount GPS/GNSS antenna (1m cable, SMA connector)
• 1× 915 MHz LoRa antenna (2 dBi gain, 50 Ω)
• 1× Mounting kit (4× brass standoffs, 4× washers)

Resources

• All the IoT – Transport Layer Guide (Adafruit Learn)
