The AM2315C is an enclosed I2C temperature and humidity sensor featuring the modern AHT20 sensor inside a rugged housing with mounting bracket. It offers the same convenient form factor as the original AM2315 but with an updated sensor that supports a wider 2.5V to 5.5V supply range, making it compatible with both 3.3V and 5V microcontrollers.

With built-in pull-up resistors and standard I2C communication, this sensor connects easily to any Arduino or Raspberry Pi. The enclosed design provides much better environmental protection than bare PCB-mounted sensors, handling wind, rain, and outdoor conditions with ease. Take readings as frequently as you like — no timing-critical protocol to worry about.

Key Features

• I2C Interface – Standard I2C communication, no bit-bang timing protocol needed
• Wide Voltage Range – 2.5V to 5.5V, compatible with 3.3V and 5V logic
• Built-In Pull-Ups – Ready to connect with no external resistors required
• Rugged Enclosed Design – Protected housing with mounting bracket for real-world installations
• AHT20 Sensor Inside – Modern, reliable temperature and humidity sensing

Specifications

• Sensor – AHT20
• Interface – I2C (single fixed address)
• Supply Voltage – 2.5V to 5.5V
• Humidity Accuracy – ±2% RH (typical, at 20–80% RH)
• Temperature Accuracy – ±0.3°C (typical, at 20–60°C)
• Housing – Enclosed with mounting bracket

Ideal For

• Outdoor and semi-exposed environmental monitoring
• Weather stations and climate logging
• Greenhouse and agricultural sensing
• IoT and home automation projects

Package Contents

• 1× AM2315C Encased I2C Temperature/Humidity Sensor (with built-in pull-ups)

Resources

• Adafruit AHT20 Guide (library code, datasheet, and more)
