ESP32-P4 Smart 86 Box – Dual-Core RISC-V, 4" 720p Touch Display

Product image 1
1 / 7

ESP32-P4 Smart 86 Box – Dual-Core RISC-V, 4" 720p Touch Display

ESP32-P4 Smart 86 Box Development Board

Power up your innovative IoT projects with the ESP32-P4 Smart 86 Box Development Board, a cutting-edge platform designed to unlock the potential of smart home automation, industrial IoT, and high-end embedded applications.
Featuring a potent ESP32-P4 Controller based on RISC-V 32-bit architecture, this board boasts both dual-core and single-core processors to deliver unparalleled processing power. Get ready for swift and seamless operation, whether you're handling complex computations or multitasking like a pro.
Exhilarating Visuals on a 4-inch Touch Display
Dive into an immersive development experience with the onboard 4-inch IPS touch display, offering a crisp 720 × 720-pixel resolution for your GUI needs. The display is not just about visual appeal; it comes with 5-point capacitive touch support to ensure that your interactions are intuitive and responsive.
Multiple Versions for Diverse Needs
Choose from two tailored versions depending on your project requirements: - ESP32-P4-WIFI6-Touch-LCD-4B: Perfect for projects requiring a camera interface and advanced visual processing. - ESP32-P4-86-Panel-ETH-2RO: Ideal for networking tasks with its Ethernet port, RS485 terminal, and 2-channel relay for power control.
Packed to the Brim with Features:
  • RISC-V 32-bit Dual-core and Single-core Processors
  • High-Performance Memory: 128 KB HP ROM, 32 KB LP SRAM, and more.
  • Integrated Image and Voice Processing Interfaces: Including a JPEG Codec, Pixel Processing Accelerator, and H264 encoder.
  • 32MB PSRAM and 32MB Nor Flash Onboard
  • Rich Connectivity Options: Depending on the version, find MIPI-CSI, MIPI-DSI, USB OTG, SDIO 3.0 TF card slot, and more.
  • Enhanced Security: With Secure Boot, Flash Encryption, and a dedicated Key Management Unit for robust protection.
Display Excellence & Durability:
  • 4-inch IPS Capacitive Touch Screen
  • Bright Display & Wide Viewing Angle: 400cd/m² brightness and 170° viewing angle.
  • High Contrast and Vivid Colors: For clear and dynamic visuals.
Control & Connectivity:
  • RS485 Interface: (For ESP32-P4-86-Panel-ETH-2RO) Stable data transmission with power isolation and protection.
  • 2-Channel Relay: (For ESP32-P4-86-Panel-ETH-2RO) Manage high-power devices with ease thanks to optocoupler isolation.
  • 100M RJ45 Ethernet Port: (For ESP32-P4-86-Panel-ETH-2RO) Reliable wired network communication support.
Audiophile Features:
  • Onboard Audio Codec Chip & Echo Cancellation: Ensuring clear audio capture for AI voice interaction and daily audio tasks.
Installation Made Easy:
With its standard 86 dimensions and modular structure, installation is straightforward and hassle-free. It is recommended to use an 86-type back box with at least a 33mm depth, with special considerations if utilizing the Ethernet port.
Expand Your Horizons:
The board’s expansion header allows for additional interfaces, ensuring that the possibilities for development are virtually endless.
Resources & Support:
Get started quickly and access continuous support with our comprehensive wiki resources: - ESP32-P4-WIFI6-Touch-LCD-4B Wiki - ESP32-P4-86-Panel-ETH-2RO Wiki
Weight: 0.095 kg
In the Box:
Depending on your choice of version, you will receive either: - ESP32-P4-WIFI6-Touch-LCD-4B × 1 - or - ESP32-P4-86-Panel-ETH-2RO × 1
Expand your creative horizon and make your smart living ideas a reality with the ESP32-P4 Smart 86 Box Development Board!
$73.00
