Memory Metal Actuator - Dash4
The Dash4 is a compact shape memory metal actuator that uses shape memory alloy (SMA) technology — originally developed by NASA — to provide silent, lightweight linear actuation. It delivers a stroke of 0.23" (5.8 mm) with over 1.75 pounds of constant actuation force, all in a package less than 0.1" thick.
A built-in limit switch enables safe operation over a wide voltage range when paired with the MAD-v5 controller (sold separately), allowing you to tune actuation speed to your application.
Specifications
- Stroke – 0.23" (5.8 mm)
- Output Force – 1.75 lb-f constant
- Actuation Time – 50 ms to position-hold
- 7V Actuation – ~2.1 A
- Resistance – 3.2 Ω
- Electrical Interface – 3-pin header on 0.1" pitch
- Mounting – 2× 2-56 screw holes
- Operating Temperature – -29°C to +60°C
- Dimensions – 68 × 38 × 3 mm (2.68 × 1.50 × 0.12")
- Weight – 10 g (0.35 oz)
Ideal For
- Lightweight robotics and grasping mechanisms
- Latch release systems and electronic locks
- Automotive mechanisms (grill louvers, fuel door, trunk release)
- Pneumatic actuator replacement in space-constrained designs
- ROVs and undersea sampling equipment
Package Contents
- 1× Memory Metal Actuator (Dash4)
