The Micro Dot pHAT is a retro-style LED matrix display board for Raspberry Pi, designed to drive up to six Lite-On LTP-305 LED matrices. Each 5×7 pixel matrix includes a decimal point, giving you an effective display area of 30×7 pixels across all six modules.

Use between 1 and 6 matrices in your choice of green and/or red for scrolling message displays, spectrum analysers, clocks, or sensor readouts. This listing is for the bare pHAT board only — LED matrix modules are sold separately.

Key Features

• 3× IS31FL3730 LED Drivers – Drives up to 6 LTP-305 LED matrices via I2C
• 30×7 Pixel Display – 5×7 pixels per matrix plus decimal point, across 6 modules
• Green and/or Red Matrices – Mix and match colours across the 6 positions
• pHAT Form Factor – Compact Raspberry Pi Zero-sized board
• Python Library – Comprehensive library for easy text scrolling and graphics
• Stackable – Works alongside other pHATs and HATs

Compatibility

• Raspberry Pi 3B+, 3, 2, B+, A+
• Raspberry Pi Zero and Zero W

Ideal For

• Retro scrolling message displays
• Compact clocks and timers
• Audio spectrum analysers
• Sensor data readouts (temperature, pressure, light)

Package Contents

• 1× Micro Dot pHAT board (bare PCB, no matrices or header included)

Resources

• Python Library (GitHub)
• Assembly Guide
• Getting Started Guide
• Pinout Reference
