A compact 0.91" OLED display module with 128 × 32 pixel resolution, capable of displaying up to 3 lines of text. As an OLED, it has no backlight — resulting in thinner construction, lower power consumption, and higher contrast compared to LCD displays. The optimised firmware updates only changed portions of the screen for efficient I2C communication.

Key Features

• 0.91" OLED Display – 128 × 32 pixels, up to 3 lines of text
• I2C / Qwiic Interface – 2× Qwiic connectors for daisy-chaining, no soldering required
• Low Power – No backlight layer, OLED pixels are self-emitting
• High Contrast – True black background with bright white pixels
• Snap-Off Mounting Holes – 4 mounting holes that can be removed to reduce size
• Optimised Refresh – Partial screen updates for efficient I2C performance

Specifications

• Display Size – 0.91" diagonal
• Resolution – 128 × 32 pixels
• Interface – I2C (Qwiic connector, 1 mm pitch 4-pin JST)
• Display Type – OLED (white on black)
