A compact, full-metal-gear DC motor with a 100:1 gear ratio, delivering up to 270 RPM and 1.8 kg·cm of stall torque at 12V. The 3 mm D-shaft makes it easy to attach wheels, pulleys, and other drivetrain components.

Specifications

• Voltage – 6–12 V DC, reversible
• Gear Ratio – 100:1 (full metal gears)
• Speed – 140 RPM (6V) / 270 RPM (12V)
• Stall Torque – 0.85 kg·cm (6V) / 1.8 kg·cm (12V)
• No-Load Current – 40 mA (6V) / 80 mA (12V)
• Stall Current – 360 mA (6V) / 1600 mA (12V)
• Shaft – 3 mm D-shaft, 10 mm length
• Motor Size – 26 × 12 × 10 mm
• Weight – 17 g

Ideal For

• Small robot drivetrains and tracked vehicles
• Motorised mechanisms and conveyor prototypes
• Educational robotics projects
