Servo Driver Module for Raspberry Pi Pico, 16-ch Outputs, 16-bit Resolution
Servo Driver Module For Pico
Ideal For Controlling Robotic Arm Or Hexapod Walker
Features At A Glance
- Standard Raspberry Pi Pico header, supports Raspberry Pi Pico series boards
- Up to 16-Channel servo/PWM outputs, 16-bit resolution for each channel
- Integrates 5V regulator, up to 3A output current, allows battery power supply from the VIN terminal
- Standard servo interface, supports common used servo such as SG90, MG90S, MG996R, etc.
- Exposes unused pins of Pico, easy expansion
- Comes with development resources and manual (Raspberry Pi Pico C/C++ and MicroPython examples)
Specifications
OPERATING VOLTAGESERVO VOLTAGE LEVELLOGIC LEVELCONTROL INTERFACEMOUNTING HOLE SIZEDIMENSIONS
5V (Pico) or 6~12V (VIN terminal) | 5V
3.3V | GPIO
3.0mm | 65 × 56mm
3.3V | GPIO
3.0mm | 65 × 56mm
Raspberry Pi Pico Header Compatibility
Onboard Female Pin Header For Direct Attaching To Raspberry Pi Pico
Standard Servo Interface
Supports Common Used Servo Like: SG90, MG90S, MG996R
Onboard 5V Regulator
Flexible Power Options: Powered From Pico Directly,
Or From VIN Battery Input Terminal With Max 3A Current Output
Or From VIN Battery Input Terminal With Max 3A Current Output
Raspberry Pi Pico and servo are NOT included.
WIKI: Pico-Servo-Driver
