A compact DC gearmotor with an integrated M3 × 25 mm threaded output shaft, turning it into a simple linear actuator. Rated at 6V with a no-load speed of 98 RPM and a 1:150 gear reduction, it delivers good torque in a tiny package weighing just 10 g.

The brass faceplate has two mounting holes threaded for M1.6 screws (1.6 mm diameter, 0.35 mm pitch). Compatible with micro metal gearmotor mounting brackets for secure installation with enclosed gears.

Specifications

• Gear Ratio – 1:150
• Rated Voltage – 6V
• No-Load Speed – 98 ±10% RPM
• No-Load Current – 24 ±10% mA (max)
• Load Speed – 60 ±10% RPM
• Load Current – 185 ±10% mA (max)
• Load Torque – 550 g·cm
• Stall Current – 420 ±10% mA (max)
• Stall Torque – 1,000 g·cm
• Output Shaft – M3 × 25 mm threaded rod
• Mounting – M1.6 threaded holes on brass faceplate
• Noise – ≤50 dB (at 10 cm)
• Weight – ~10 g

Ideal For

• DIY linear actuators
• Small robotics platforms
• Motorised mechanisms and linkages
• Micro gearmotor projects

Package Contents

• 1× Micro Metal DC Geared Motor with Long Shaft (6V, 98 RPM)
