The MB7574 SCXL-MaxSonar-WRST7 is a weather-resistant ultrasonic distance sensor designed for outdoor use. It provides millimetre-resolution measurements from 500mm to 5000mm with a 0.58Hz read rate, and includes three output options: analog voltage, TTL serial, and pulse-width.

Housed in a compact IP67-rated PVC enclosure compatible with standard 3/4-inch PVC pipe fittings, the sensor features a self-cleaning transducer to reduce the impact of condensation and frost. Internal temperature compensation and real-time automatic calibration ensure accurate readings across varying environmental conditions.

Key Features

• Weather Resistant (IP67) – Rugged PVC housing suitable for outdoor and high-moisture environments
• Self-Cleaning Transducer – Reduces impact of condensation, frost, and debris
• 1mm Resolution – High-precision distance measurements with rate-limiting filter
• Three Output Modes – Analog voltage, TTL serial, and pulse-width
• Internal Temperature Compensation – Accurate readings without external calibration
• Real-Time Automatic Calibration – Compensates for voltage, humidity, and ambient noise
• Advanced Noise Rejection – Waveform signature analysis and continuously variable gain for clean readings
• Narrow Beam Pattern – Factory calibrated for long-range, focused detection

Specifications

• Model: MB7574 SCXL-MaxSonar-WRST7
• Range: 500mm to 5000mm
• Resolution: 1mm
• Read Rate: 0.58Hz
• Frequency: 42kHz ultrasonic
• Supply Voltage: 2.7–5.5V
• Current Draw: 68mA average
• Outputs: Analog voltage, TTL serial, pulse-width
• Operating Temperature: -40°C to +65°C
• Ingress Protection: IP67
• Housing: PVC, compatible with 3/4" pipe fittings
• Compliance: RoHS

Ideal For

• Snow depth and water level measurement
• Weather station monitoring
• Outdoor distance sensing and object detection
• Industrial and environmental monitoring

Package Contents

• 1× MB7574 SCXL-MaxSonar-WRST7 Ultrasonic Sensor

Resources

• SCXL-MaxSonar-WRS Datasheet (PDF)
